Especificaciones
Aplicación
Client PCs, Game Consoles
Interfaz
PCIe Gen 4.0 x4, NVMe 2.0
Dimensiones
80 x 22 x 2.3 mm
Peso
Max 9.0g Weight
Rendimiento
Up to 7,450 MB/s * Performance may vary based on system hardware &
configuration
Escritura secuencial
Up to 6,900 MB/s * Performance may vary based on system hardware &
configuration
Detalle de especificaciones
Características generales
Aplicación
Client PCs, Game Consoles
Capacidad
2,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to
formatting, partitioning, operating system, applications or otherwise)
Formato
M.2 (2280)
Interfaz
PCIe Gen 4.0 x4, NVMe 2.0
Dimensiones
80 x 22 x 2.3 mm
Peso
Max 9.0g Weight
Memoria de almacenamiento
Samsung V-NAND 3-bit MLC
Controller
Samsung in-house Controller
Memoria caché
Samsung 2GB Low Power DDR4 SDRAM
Características especiales
Soporte TRIM
Supported
Soporte S.M.A.R.T
Supported
GC (Garbage Collection)
Auto Garbage Collection Algorithm
Encriptación
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN
Not supported
Soporte Modo Suspensión en dispositivo
Sí
Rendimiento
Lectura secuencial
Up to 7,450 MB/s * Performance may vary based on system hardware &
configuration
Escritura secuencial
Up to 6,900 MB/s * Performance may vary based on system hardware &
configuration
Lectura aleatoria (4KB, QD32)
Up to 1,400,000 IOPS * Performance may vary based on system hardware &
configuration
Escritura aleatoria (4KB, QD32)
Up to 1,550,000 IOPS * Performance may vary based on system hardware &
configuration
Lectura aleatoria (4KB, QD1)
Up to 22,000 IOPS * Performance may vary based on system hardware &
configuration
Escritura aleatoria (4KB, QD1)
Up to 80,000 IOPS * Performance may vary based on system hardware &
configuration
Entorno
Consumo energético medio
*Average: 5.5 W*Maximum: 8.5 W (Burst mode)* Actual power consumption may
vary depending on system hardware & configuration
Consumo energético (Idle)
Max. 55 mW * Actual power consumption may vary depending on system
hardware & configuration
Voltaje soportado
3.3 V 5 % Allowable voltage
Durabilidad (MTBF)
1.5 Million Hours Reliability (MTBF)
Temperatura
0 - 70 Operating Temperature
Golpes
1,500 G & 0.5 ms (Half sine)
Accesorios
Kit de instalación
Not Available
Software
SW de gestión
Magician Software for SSD management
